Nano-D connectors - ZC32139 series
The Zhuyao Connectors ZC32139 series is rugged nano-miniature Nano-D connectors are designed for applications where minimizing size & weight are essential, and ruggedness and reliability are mission critical. Rugged Nano-D metal shell connectors are commonly used in unmanned aerial vehicles, air taxis, satellites, petrochemical, medical device applications and more. ZC32139 Series is available in I/O pre-terminated flying leads and vertical and right-angle board-mount models. Zhuyao Connectors ZC32139 series meet the requirements of MIL-DTL-32139.
Key features:
- 0.635 mm (.025") contact spacing (double the density of a Micro-D)
- 9-91 contacts
- 1 & 2 row options
- 3 reliable points-of-contact
- High-reliability twist pin contacts
- Metal shell construction with captivated hardware
- Also avalible custom-designed Nano miniature connectors
- MIL-DTL-32139 qualification
- Avionics, gimbals, radars.
- Missiles and guidance systems
- On-board equipment, telecommunication systems
- Navigation systems
- Research centres
- Medical applications
